1360m3/h Fresh Air Handling Units For Workshop Cooling

Product Details:
Place of Origin: China
Brand Name: NEW
Certification: ISO9001
Model Number: FP-136
Payment & Shipping Terms:
Minimum Order Quantity: 5sets
Price: USD200~400
Packaging Details: Carton box
Delivery Time: 20 days after got deposit payment
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 10000sets/month

Detail Information

FCU Type: Go Through Chilled Water Chilled Temperature: In/outlet 12C/7C
New Design: Fresh Air Connection Air Outlet: 4-ways
Voltage: 220V 1ph 50hz Customize Voltage: Available
Air Flow: 1360m3/h Unit Size: 710*710*290mm
Panel Size: 800*800*30mm Net Weight: 25kgs
In/outlet Pipe: DN20 Drain Water Pipe: 25mm
Application: Hotel, Office, Shopping Mall, Hospital
High Light:

1360m3/H Fresh Air Handling Units


ISO9001 fresh air handling units

Product Description

Fresh Air Handling Unit Workshop Cooling Industrial Fan Coil Unit


Features of Cassette Fan Coil Unit

- Sensible and latent heat recovery

- Easy adjustment and maintenance

- No condensation, no water leakage

- The operation is quiet and never rusts
- High flexibility and low installation cost

- The structure is exquisite, firm and durable.

- Matching hydrophilic aluminum fin to wear copper tube
- Compact structure and galvanized panels against the corrosion
- Air return box is optional, which can ease installation, reducing construction cost
- High performance, high efficiency and low power consumption.

Comfortable horizontal cassette magic air fan coil unit

Item No Size(Cm) Voltage(VAC) Volume(m3/h) Power Cooling capacity(kw/h) Heating Capacity(kw/h) Noise Weight
FP-34 58*58*25 220-240 340 34w 1.98 2.98 37A 21KG
FP-51 58*58*25 220-240 510 50w 2.98 4.80 39A 22KG
FP-68 58*58*25 220-240 680 58w 3.68 5.48 41A 23KG
FP-85 80*80*30 220-240 850 72w 4.98 7.20 43A 30.5KG
FP-102 80*80*30 220-240 1020 92w 5.58 8.18 45A 31KG
FP-136 80*80*30 220-240 1360 126w 7.20 10.80 46A 31.5KG
FP-170 95*95*30 220-240 1700 128w 9.90 14.50 47A 38.5KG
FP-204 95*95*30 220-240 2040 152w 10.80 16.20 49A 39.5KG
FP-238 95*95*30 220-240 2380 198w 12.60 18.90 52A 40.5KG
