2 Stage -80℃ Outlet Low Temperature Chillers

Product Details:
Place of Origin: China
Brand Name: New
Certification: ISO9001
Model Number: SC-15ULWC3
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 60,000.00-65,000.00
Packaging Details: Wooden case or Plastic film
Delivery Time: 45 days after got deposit payment
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 20 sets/month

Detail Information

Evaporator In/outlet: -75C/-80C Cooling Capcity: 15KW(Base On -80C)
Input Power: 33kw Compressor: Double Stage Screw Compressor
Heat Exchanger: Plate Type And Shell And Tube Type Touch Panel: 10 Inch
Power Supply: 380V 3ph 50hz Refrigerant: R404a And R32
Circuit: 2 Circuit And 2 Stage Color: Milk White Or Green Or Customize
High Light:

-80℃ Outlet Low Temperature Chillers

,

2 Stage Low Temperature Chillers

Product Description

China High Quality Cheap Price OEM ODM Industrial Water Chiller Manufacturer





Specification:

Cooling Capctity KW 16
Power Supply   3φ 380V 50Hz
Input Power KW 39.2









First stage
Compressor

Type   Semi-enclosed piston
Brand   Dorin from Italy
Refrigerant   R404
Refrigerant capacity   38KG
Capacity Control % 25%,50%,75%,100%
Input Power kw 21
Compressor Oil Model BSE32
Throttling way Expansion Valve
Second stage Compressor Type   Semi-enclosed piston
Brand   Dorin from Italy
Refrigerant   R23
Input power kw 18.2
Compressor oil model BSE32
Throttling way Expansion Valve



Condensing Evaportor

Type   SS #304 Plate type Heat Exchanger
R23 In/outlet temperature 50℃/-30℃
R404A In/outlet temperature -35℃/-20℃



Evaportor

Type   High-efficiency Plate type Heat exchanger
anhydrous alcohol m3/h 7
Evaporating temperature -85℃





Condenser

Type   Shell and Tube water-cooled
Water Flow m3/h 16
Condensing temperature 30℃
30% Heat recover Type Shell and Tube water cooled
Water temperature 70-80C
Pipe size Evaportor mm DN65

2 Stage -80℃ Outlet Low Temperature Chillers 0

Applications:



Water Chillers are applicable to places such as chemical factory, pharceutical factory, industrial cooling...



Notice: Any Non-standard design water chiller welcome to send us details information. OEM and Customize service available.
