Air Cooled -80℃ Low Temperature Glycol Water Chiller

Product Details:
Place of Origin: China
Brand Name: New
Certification: ISO9001
Model Number: SC-80DWS3
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: wooden case or Plastic film
Delivery Time: 35 working days after got deposit
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 50 sets/month

Detail Information

Working Temperature: -80C To -5C Working Voltage: 380V-400V 3ph 50hz
Input Power: 25kw Glycol Liquid: In/outlet -75C/-80C
Evaportor: Shell And Tube Go Through 80% Glycol Liquid Condenser: Shell And Tube
Color: Green Or Customize Refrigerant: R404a,R23
Controller: 7 Inch Application: Ice Rink, Chemical Factory, Pharceutical Factory, Industrial Cooling
High Light:

Low Temperature Glycol Water Chiller


-80℃ Glycol Water Chiller


25kw Low Temperature Chillers

Product Description

SC-80DAS3 Low Temperature Air Cooled Glycol liquid Water Chiller Mixed with 30% ethylene glycol






No-load Min.Temperature -80℃
Internal and external circulation Closed circulation system
Performance Cooling Temp. Range -80℃~RT
Constant Temperature ±0.5℃



20℃ 25620W
0℃ 24132W
-40℃ 2552W
-60℃ 913W
-80℃ 357W



Show temp. setting way Digital Settings for keys,LED Digital display( smallest unit:0.1℃)
Temp. sensor graduation PT100
Set way Materials temperature control mode
Main Parts Refrigerant R404A+R23
Compressor 2X6P(9000W)
Condenser Copper tube, air-cooled condenser
Plate heat exchanger High efficiency and compact
Circulating pump Power:280W, Flow: 30-50L/min, Lift:10-12m
Security protection

Delayed, overshoot current, compressor overheating

(pressure gauge display), overload relay, emergency stop switch device. and partially temporary stop button.



Operating environment ≤25℃
Relative humidity 45-85RH%
Barometric pressure 86-106Kpa
Voltage 380V/50Hz, 3-phase




Applications:Air Cooled -80℃ Low Temperature Glycol Water Chiller 0


Water Chillers are applicable to places such as Ice Rink cooling, chemical factory, pharceutical factory, industrial cooling...


Notice: Any Non-standard design water chiller welcome to send us details information. OEM and Customize service available.


Air Cooled -80℃ Low Temperature Glycol Water Chiller 1

Air Cooled -80℃ Low Temperature Glycol Water Chiller 2

Air Cooled -80℃ Low Temperature Glycol Water Chiller 3

Air Cooled -80℃ Low Temperature Glycol Water Chiller 4
