0.6hp Laser Water Chiller 220V Custom With Scroll Compressor

Main components
Laser chiller is mainly composed of water tank, compressor, condenser, evaporator, capillary and so on.

Portable Small Water Chiller Features

1. The portable air cooled industrial chiller uses in small to medium cooling loads. Typically, available for 3 to 185 kW (0.85 to 52.6ons) with scroll compressor.
2. This 0.6hp laser chiller designed with Panasonic scroll compressor, efficient V-type condenser, Danfoss or Copeland thermostatic expansion valve, S.S 304 water tank and Schneider electric component.
3. The portable chillers are complete safety devices are equipped ,including compressor over temperature, over current, high and low pressure, over temperature, flow switch, etc. to ensure the chiller unit running stably with long service time.
4. Environment-friendly refrigerant R407C, R410A, R404A, R134a, etc, which is no harm to the ozone layer.
5. The industrial water chillers are designed with micro controller to ensure control accuracy. The interface is displayed in English, easy operation.

Benefits of an laser water chiller

1. Laser chiller is used to maintain constant and precise control of the laser generator to reduce downtime and improve the service life.
2. The water chiller precise temperature control can improve the machining accuracy of laser machine and productivity for laser process.
3. Industrial chiller is usually closed-loop systems, which can save water through recirculation cooling.
4. Portable laser chiller contains water tank and the pump and all necessary components, portable and easier installation.
5. The air cooled laser chiller is without additional cooling tower and water pump, easier operation and maintenance.

Water quality and material requirements for laser chiller water systems​

The waterway inside the laser is narrow, if there are impurities in the circulating water, it is easy to block the waterway, so the laser has a high requirement on the water quality of the circulating water of the chiller. The water system of laser chiller must be made of stainless steel to prevent rust and other impurities. At the same time, it is recommended to use distilled water or clean purified water as the circulating water of cooling time.
