Home ProductsLaser Water Chiller

5W Air Cooled Small Laser Chiller Unit Laser Cooling Machine

All Products

Industrial Water Chiller

(10)

Air Cooled Water Chiller

(16)

Water Chiller Machine

(1)

Air Cooled Screw Chiller

(16)

Water Cooled Screw Chiller

(11)

Explosion Proof Chiller

(20)

Low Temperature Chiller

(20)

Portable Water Chiller

(1)

Water Chiller Unit

(1)

Chemical Chiller

(4)

Laser Water Chiller

(18)
Certification
China Dongguan Ruixiang Machinery Co., Ltd certification
I'm Online Chat Now

5W Air Cooled Small Laser Chiller Unit Laser Cooling Machine

5W Air Cooled Small Laser Chiller Unit Laser Cooling Machine
5W Air Cooled Small Laser Chiller Unit Laser Cooling Machine

Large Image :  5W Air Cooled Small Laser Chiller Unit Laser Cooling Machine

Product Details:
Brand Name: Ruixiang
Certification: ISO9001/CE
Model Number: RX-5HP
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: RMB 6500-800000/PC
Packaging Details: Wooden Box Packaging
Delivery Time: 15-20 Units
Payment Terms: T/T
Supply Ability: 500days
Contact Now

5W Air Cooled Small Laser Chiller Unit Laser Cooling Machine

Description
Condenser Type: High Efficiency Finned Heat Exchanger Protection Function: High And Low Pressure Protection, Overload Protection, Water Flow Protection, Phase Sequence Protection, Etc.
Type: Air-cooled Temperature Range: 5-35℃
Warranty: 2 Years Refrigerant Type: R410A
Power Supply: 220V/380V
Highlight:

5W Laser Chiller Unit

,

5W Laser Cooling Machine

,

Air Cooled Laser Cooling Machine

5W Air Cooled Small Laser Chiller Unit Laser Cooling Machine

Product Description

Laser Chiller 5W Air Cooled Small Chiller Laser Cooling Machine Laser Cutting Cooling Cooling Laser



Laser chiller

Laser chiller is a kind of water cooling equipment, can provide constant temperature, constant current, constant pressure cooling water. Laser water cooler is mainly used in laser marking machine, laser engraving machine, laser welding machine, laser injet machine, laser cutting machine and other laser processing equipment, it can precisely control the temperature required by laser equipment, so as to ensure the normal work of laser equipment.



Industrial Laser Chiller Specification

Item AL-5W
Nominal cooling capacity Kcal/h 12470
  kw 14.5
Input power kw 5.33
Power supply 3PH~380V/50HZ
Refrigerant Type R22
  Type of control Capillary
Compressor Type Hermetic scroll type
  Power (kw) 4.4
Condenser Type

Finned copper tube+low noise outer

rotor fan
  Power(kw) 0.38
  Cooling air flow 5000
Evaporator Type Water tank with coil
  Chilled water flow 2.50
  Tank volume(L) 60
  Inlet/outlet pipe chiller(inch) 1
Water pump Power(KW) 0.55
  Lift(m) 22
Safety protection compressor over temperature, over-current protection, high and low pressure protection, over -temperature protection ,flow switch protection,phase sequence or missing phase protection,exhaust overheating protection
Net weight kg 175
Dimension mm 1140*560*1250


Why do I need a industrial water chiller?

Industrial chillers are used for controlled cooling of products, mechanisms and machinery in a variety of industries. A chiller removes heat from the process water and transfers it to air via a heat exchanger.Industrial water chiller can keep your equipment at a safe operating temperature and cool your components during processes to ensure the highest quality final products and reduce production cycle time.



Main components
Laser chiller is mainly composed of water tank, compressor, condenser, evaporator, capillary and so on.



Industrial chiller application
Laser chiller provides constant temperature, constant current, constant pressure environment in medical, electroplating, plastic, numerical control and other industries.



Featurers for laser cutting chiller
1.Laser chiller use the world famous hermetic scroll type compressor, features low noise, low vibration, low energy consumption and high efficiency.
2.Laser chiller use environmental refrigerant R410a or R134a.
3.Air cooled laser chiller use finned copper tube and low noise outer rotor fan, without cooling water system, save water.
4.High efficient shell and tube type or plack pack evaporator, built-in stainless steel 304 water tank, easy to install and use.
5.Chiller has accurate temperature control capability, the chilled water temperature can be accurate to ± 0.5 ℃.
6.The air coole package laser chiller has contains water tank and the pump and all necessary components, portable and easier installation.





Benefits of a laser water chiller
1.The laser chiller cooling provide constant and precise cold water to the laser process temperature.
2.The water chiller precise temperature control can improve the machining accuracy of laser machine and productivity for laser process.
3.Air cooled laser chiller design is very compact and made of high-grade materials. It has stronger durability and longer service life.
4.Chillers can decrease equipment depreciation and degradation to cut down on operating expenditures.

The daily maintenance method of laser chiller:
1.Install the chiller in a ventilated and clean place, ambient temperature below 40 ℃ is recommended and maintain good ventilation.
2.The water should be replaced regularly, and the water tank should be cleaned regularly. Generally, the water should be changed once every 3 months.
3.The quality and temperature of the circulating water will affect the service life of the laser tube, so it is recommended to use pure water.
4.When the lase chiller stops due to fault alarm, must check the cause of the fault. Do not forcibly start the chiller before troubleshooting.
5.Regularly clean the condenser and dust filter of the chiller.
6.If there is no emergency during use, do not arbitrarily shut down the chiller by cutting off the power supply.
7.Winter maintenance in addition to routine maintenance, there is also the need to prevent icing. In order to ensure the normal use of laser chiller, the ambient temperature should not be lower than 5 ℃.If not, add antifreeze solution appropriately.

Tag:

water chiller for laser cutter,

laser water cooler,

laser engraver chiller
